rotary gear limit switch

WL-D2 dc switch / 12v Limit Switch / Micro Limit Switvh long life limit swith magnetic limit switch price micro limit switches

WL-D2

Delivery

FOB

minimum order

500 pieces

Supply Ability

10000.0pieces / Month

Country of Origin

Ningbo / Shanghai

Quantity

Contact Now

add to cart

limit switch
limit switch
limit switch
limit switch
limit switch
limit switch
Operation speed:1mm ~ 1m /s
Contact resistance:15mΩ max. (initial value)
Insulation resistance:100mΩ min. (at 500VDC)
Mechanical Life:10^7 operations min.
Degree of protection:IEC specification: IP67
Place of Origin:CN;ZHE
Brand Name:Titcha
Model Number:WL-D2
Protection Level:IP65
Operating Temperature:- 20 to 60 ℃
Max. Current:15A
Max. Voltage:250VAC

Product Description

Rated working current	15A 500V,250VAC; 50/60Hz
Contact type	Contact resistance (initial value )		Under 15 mΩ (no include copper resistance )
	Contact material		Sliver cadmium oxide contact(if no need cadmium,[according with ROSH certificate ] can customize
Electrical	Insulation resistance (initial value)		100 mΩ min. (use the DC500V insulation resistance test)
	Dielectric strength		Between Non-continuous terminals (initial value): 1500V 50/60HZ for 1 min Between non voltage metal parts and each terminal: 2000V 50/60HZ for 1min Between ground and each terminal: 2000V 50HZ for 1 min
Mechanical	Shock resistance	In the free position	Less than 98m/s2(10G)
		In the full operating position	Less than 294m./s2(30G)
	Vibration resistance		1.5mm double amplitude 10-55HZ
Expected Life	Mechanical		10,000,000 operations min. (on/off frequency 120 operations/min)
	Electrical		300,000 operations min. (rated load ), electromagnetism contactor FC-100(AC200V) load ; 5,000,000 operations min.
Using condition	Ambient temperature /Ambient humidity		-20~+60 95%RH max. (at +5~20)
	The max on/off frequency		120 operations/min

Model	WL-D2
OF (Max.)	2720g
RF (Min.)	910g
PT (Max.)	1.7mm
OT (Min.)	5.6mm
MD (Max.)	1mm
TF (Max.)	-
TT (Min.)	OP: 6.5±0.8mm
