G7L-2A-T Power Relay professional product
G7L-2A-T
Delivery
FOB
minimum order
1000 pieces
Supply Ability
200000.0pieces / Month
Country of Origin
Shanghai / Ningbo
Type
Quantity
- Case color:black
- Theory:Voltage Relay
- Usage:General Purpose
- Size:Miniature
- Protect Feature:Sealed
- Contact Load:High Power
- Place of Origin:CN;ZHE
- Brand Name:TiTCHA
- Model Number:G7L-2A-T
Power relay
Power relay
Power relay
Power relay
Power relay
Power relay
Power relay
Features of Power Relay G7L-2A-T:
1.30A contact overating capacity
2.Dust-proof cover & sealed plastic type
3.PCB terminal
Size(mm): 68.5×33.5×47
Tirminal layout:1H/2H
Contact capacit:30A 28VDC/30A 220VAC
Contact resistance:≤50mΩ
Inulation resistance:≥500MΩ
Dielectric strength:BOC 1500VAC/BCC 2500VAC
Technical Parameter:
Mode | JQX-62F-1Z | JQC-62F-2Z | G7L-2A-T | |
Coil nominal voltage | DC 6 to 220V | DC 6 to 220V | DC 6 to 24V | |
AC 6 to 380V | AC 6 to 380V | AC 6 to 220V | ||
Coil nominal power | DC≤3.3W | DC≤4W | DC≤2.0W | |
AC≤5VA | AC≤6VA | |||
Electrical life | 105OPS | 105OPS | 105OPS | |
Mechanical life | 106OPS | 106OPS | 106OPS |
Weight | ≤210g | ≤340g | ≤100g | |
Mounting methods | Scfrew Mounting | Scfrew Mounting | Outlet |
